IDECYW1L-MF2E11QM3W Illuminated Pushbutton 22mm Extended w/Full Shroud Momentary White 230/240VAC/DC 1NO+1NC

Product Code: YW1L-MF2E11QM3W

  • Illuminated pushbutton with white LED lamp
  • IP65 front protection, IP20 terminal
  • Operates in -20 to 55°C environment
  • Mechanical life up to 5 million operations
  • CE, cULus, UKCA, CCC certified
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 30W x 41.4H x 64.8D
Operating Voltage DC (V) 230/240
Operating Voltage AC (V) 230/240
No. of Normally-open Contacts 1
No. of Normally-closed Contacts 1
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Extended with Full Shroud
Bezel Material Plastic
Colour White
Contact Configuration 1NO+1NC
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 22 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour White
Lamp Type Built-in LED
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Model Extended With Full Shroud Momentary- With LED Lamp
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Rated Voltage 230/240 VAC/DC
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Terminal Type Screw
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW1L-MF2E11QM3W is a compact, illuminated pushbutton with a momentary shroud designed for efficient use of space. It features a slim 10mm contact block and a removable operator for easy maintenance. The unit's lightweight design is complemented by a durable metal bezel. Its separate contact block simplifies the installation and removal process, enhancing user convenience. This pushbutton is an ideal choice for streamlined and reliable operation in various applications.
