Specifications

Product Type	Process Performance - Aluminum Motor
Brand	ABB
Colour	Blue
Connection Type	DELTA - 400 V in D & 690 V in Y
Degree of Protection	IP55
Dimensions	555 mm x 340 mm x 395 mm
Efficiency	IE3
Frame Size	132
Rated Power	7.5 kW
Weight	67.56 kg
Mounting Method	Foot/flange-mounted, term. box top, IM B35, IM 2001
Motor Poles	2
Motor Speed	3000 RPM
