Specifications

Product Type	Motor
Brand	ABB
No. of Poles (NO/NC)	2 Pole
Rated Operational Voltage (Ue)	400 V
Rated Power at 400V (Pe) - Heavy Duty	55 kW
Rated Power at 400V (Pe) - Normal Duty	55 kW
Control Features	Direct On Line
Rated Frequency	50 Hz
Integrated Motor Overload Protection	Yes
Depth	854 mm
Height	560 mm
Weight	335 Kg
Width	450 mm
IP Rating	IP55
Ambient Temperatures	-20 °C to +60 °C
Standards and Approvals	IEC 60034-1, IEC 60034-30-1
