<p>The S800P Series MCB is a robust solution for managing electrical circuits in industrial and commercial applications. Designed with precision, this miniature circuit breaker (MCB) offers reliable protection for your electrical systems, ensuring both safety and efficiency.</p><p>With a rated current of 125 A, it meets the demands of high-load environments. The device operates efficiently within a rated voltage range of 400/690 VAC, supporting diverse electrical setups. Its impressive breaking capacity of 50 kA ensures that it can handle significant fault currents without compromising performance.</p><p>Safety is paramount with the S800P Series MCB. It boasts an IP20 degree of protection, safeguarding against accidental contact with live parts. This makes it suitable for installation in controlled environments where dust and moisture are minimal concerns. Additionally, its compliance with IEC/EN 60947-2 and UL 1077 standards underscores its reliability and adherence to international safety norms.</p><p>For ease of installation, this MCB features a DIN rail mounting type which simplifies integration into existing panels or enclosures. The tightening torque value stands at 3.5 N-m, providing secure connections without the risk of over-tightening.</p><p>The unit&#39;s dimensions are carefully considered to optimize space utilization: measuring 63 mm in width, 95 mm in height, and 82.5 mm in depth. Despite its compact size, it doesn&#39;t compromise on functionality or durability—qualities reflected in its weight of just 0.515 kg.</p><p>Performance under varying environmental conditions is assured with an ambient temperature range from -25 to 60 degrees Celsius. This adaptability makes it suitable for diverse Australian climates—from cooler southern regions to hotter northern areas.</p><p>Moreover, the S800P Series MCB supports both flexible (1-50 sq-mm) and rigid (1-70 sq-mm) connecting capacities—offering versatility when dealing with different types of wiring setups commonly found across various installations.</p><p>The curve type C characteristic allows for moderate overload protection while accommodating typical start-up currents seen in motors or transformers—a valuable feature for those looking to balance sensitivity and robustness effectively.</p><p>In terms of technical specifications critical to professionals assessing suitability: the rated impulse withstand voltage is set at an impressive 6 kV while maintaining a power loss figure at only 18.8 W—ensuring energy efficiency remains uncompromised even during peak operation periods.</p><p>Finally, attention should be given to wire stripping length which measures precisely at19 mm—facilitating straightforward preparation during setup processes without unnecessary material wastage or additional labor costs involved due solely because incorrect lengths were used initially by mistake!</p><p>This product represents dependable engineering excellence tailored specifically towards meeting demanding requirements often associated directly within sectors such as manufacturing plants alongside commercial facilities alike where uninterrupted service continuity ranks highly amongst priorities shared universally among operators worldwide today!</p>
