Specifications

Product Type	Moulded Case Circuit Breaker
Brand	ABB
Connection Type	Front
Current Setting Range	70-100 A
Degree of Protection	IP20
Main Circuit Connecting Capacity	85-200 sq-mm
Number of Poles	3
Power Loss	6.2 W
Rated Current	100 A
Rated Short Circuit Current	500-1000 A
Rated Voltage	600/600 VAC/VDC
Release Type	TM
Standards and Approvals	UL 489
Suitable For Use With	XT4L
Terminal Type	Bolt
Trip Unit	TMA
Weight	2.5 kg
Width	105 mm
